- California residents
- California and Utah residents (Utah effective 7/1/18): this water heater does not meet ULTRA LOW NOX (ULN) emissions requirements, regulations prohibit the sale, shipment or installation of this water heater in any air quality district that requires ULN water heaters
- Texas residents: this water heater does not meet Low NOX (LN) emissions requirements. regulations prohibit the sale, shipment or installation of this water heater in any air quality district that requires Low NOX water heaters
- Space saver design: the short heights and narrow jacket diameters, plus the top, front and rear water inlets/outlets offer the ultimate in installation flexibility
- System sentinel LED diagnostic system: our exclusive diagnostic system, with glowing LED lights, verifies system operation sequence by sequence
- Strong tank design: universals proprietary steel formulation, patented multi-flue design, combined with 2 coats of porcelain enamel, results in a superior heat exchanger design
- Stainless steel burners: precision burners, raised port design, are formed from high chromium stainless steel; each burner assembly slides out like a drawer for quick inspection and maintenance
- Low profile automatic flue damper: low profile damper minimizes overall product height and heavy-duty vent hood supports are designed to withstand the rigors of installation
- Easy to service: factory installed full port, full flow brass drain valve allows for faster draining and servicing and hand-hole cleanout for easy removal of lime/sediment deposits
- Direct spark to pilot ignition system: saves energy by igniting only when there is a call for heat
- Built-in corrosion resistance: patented anode design utilizes multiple magnesium rods to ensure corrosion resistance for a long tank life
- Fully insulated: energy saving sag and moisture proof fiberglass insulation surrounds the storage tank and heavy mineral wool insulation surrounds the combustion chamber
- Insulation: sag and moisture proof fiberglass insulation surrounds the storage tank and heavy mineral wool insulation surrounds the combustion chamber
- Gas control system: thermostat adjusts from 100°F to 180°F, 24-Volt combination gas valve includes main gas pressure regulation, on-off manual valve, 120/24-Volt transformer and high limit temperature cut-out
- Need a different configuration, no problem; our universal line offers water heaters in 35 Gal. to 100 Gal. models available in a range BTU/h in natural gas and liquid propane
- Call 1-855-400-2552 before noon for same-day installation service in most areas, or
Features
| Item Weight | 640 |
| Uniform Energy Factor | 0 |
| Returnable | 90-Day |
| Tank Lining Material | Glass |
| Commercial/Residential | Commercial |
| Application Type | Commercial |
| Tank Warranty | 3 Year |
| Product Weight (lb.) | 640 lb |
| Wattage (watts) | 0 |
| Recovery Rate at 90F Rise (gallons/hour) | 388 |
| Maximum Temperature (F) | 180 |
| Water Heater Profile | Tall |
| Finish Family | Gray |
| Water Heater Features | Overheat Protection,Temperature Pressure Relief Valve |
| Minimum Temperature (F) | 70 °F |
| Indoor/Outdoor | Indoor |
| Fuel Type | Gas |
| BTU Rating | 360000 |
| Pack Size | 1 |
| Vent Type | Atmospheric |
| Nominal Tank Capacity (gallons) | 65 |
| Household Size | 5 |
| Tank Valve Size (in.) | 1.5 |
| Product Width (in.) | 26.25 in |
| Product Depth (in.) | 26.25 in |
| Water Connection Size (in.) | 1.5 |
| Product Height (in.) | 70.75 in |
| Part Warranty | 1 Year |
| Labor Warranty | No Warranty |
| Certifications and Listings | CSA Listed,UL Listed |
